Philips HID-PV C 35 S CDM on Sale

$21.32

25 people are viewing this right now
17 products sold in last 16 hours
Selling fast! Over 3 people have this in their carts
  • Check Mark Estimated Delivery : Up to 4 business days
  • Check Mark Free Shipping & Returns : On all orders over $200
  • Visa Card
  • MasterCard
  • American Express
  • Discover Card
  • PayPal
  • Apple Pay
Guaranteed Safe And Secure Checkout

Philips HID – PrimaVision Compact Electronic Ballast for 35w CDM lamps – HIDPVC35 S



Specifications

General Information

Remarks
UK importer address: Signify Commercial UK Limited, 3, Guildford Business Park, GU2 8XG
Type version
ng
Lamp type
CDM
Number of lamps
1 piece unit
Suitable for outdoor use
No
Number of products on MCB (16 A type B) (nom.)
24
Automatic restart
Yes
Operating and Electrical

Input Voltage
220 to 240 V
Input frequency
50 to 60 Hz
Operating frequency (nom.)
0.14 kHz
Power factor 100% load (nom.)
0.95
Ignition voltage (max.)
4.0 kV
Ignition switch-off time (nom.)
18 min
Mains voltage performance (AC)
-10%-+6%
Mains voltage safety (AC)
-18%-+10%
Inrush current width
0.25 ms
Constant wattage deviation
-3% +3%
Power losses (nom.)
4.5 W
Inrush current peak (max.)
26 A
Efficiency at full load [%]
84.7 %
Wiring

Cable capacity output wires mutual (nom.)
100 pF
Cable length from device to lamp
1.5 m
Ballast contact wire cross section
0.50-2.50 mm²
Connector type
Insert
System characteristics

Rated ballast-lamp power
35 W

Temperature

T-ambient (max.)
55 °C
T-ambient (min.)
-20 °C
T storage (max.)
80 °C
T storage (min.)
-25 °C
T-case lifetime (nom.)
80 °C
T-Case maximum (max.)
80 °C
Mechanical and Housing

Housing
S

Approval and Application

Active temperature protection
Yes
EMI 9 kHz … 300 MHz
CISPR 15 ed 7.2
Safety standard
EN 61347-2-12
Quality standard
ISO 9000:2000
Environmental standard
ISO 14001
Harmonic current emission standard
EN 61000-3-2
EMC immunity standard
EN 61547
Vibration standard
IEC68-2-6 F c
Bumps standard
IEC 68-2-29 Eb
Humidity standard
IEC 928-13
Approval marks

CE marking

ENEC certificate
Humming and noise level
37 dB(A)
Product Data

Full product code
872790085962100
Order product name
HID-PV C 35 S CDM 220-240V 50 60Hz NG
EAN UPC – product
8711500881687
Order code
85962100
Local order code
PVC035SCDM
SAP numerator – quantity per pack
1
Numerator – packs per outer box
12
SAP material
913700652766
SAP net weight (piece)
0.216 kg
Title

Default Title
